Description
The Ohaus Rocking Shaker boasts several features designed to enhance its functionality. It operates with a rocking motion at a tilt angle of 15°, providing a see-saw action that is suitable for a variety of applications. The shaker supports a maximum capacity of 4.5 kg and offers a speed range from 1 rpm to 50 rpm, ensuring efficient mixing and agitation. Users can set the timer from 1 second to 160 hours, allowing precise control over shaking durations.
The shaker is equipped with independent LED displays for speed, tilt/angle, and time settings, enhancing user visibility and control. It features a durable 32.4 x 25.4 cm aluminum tray with a rubber non-slip mat for secure placement of samples or containers. Built with a robust cast aluminum housing, the shaker includes overload protection and audio/visual alarms for safety during operation. It utilises a stepper motor drive system and digital control interface to maintain reliability and accuracy in mixing applications.
Features of the Ohaus Rocking Shaker :
- Rocking Motion
- Maximum Capacity 4.5kg
- Speed Range 1rpm to 50rpm
- Timer 1s to 160h
- Independent LED Displays
- Aluminium Tray 32.4 x 25.4 cm
- Rubber Non-Slip Mat
- Cast Aluminium Housing
- Overload Protection
- Audio/Visual Alarms
- Stepper Motor Drive System
- Digital Control
Data Sheet for the Ohaus Rocking Shaker 15° SHRK04DG
Manual for the Ohaus Rocking Shaker 15° SHRK04DG
If you see any accessories on the data sheet which you need, but can’t see on our website, please give us a call on 01257 270 433, or send us a message, and we’ll be happy to help.
