Description
The Hydrolab Ultra produces Type I water, from an inlet feed of Type III prefiltered water. It uses an ion exchange module, 254 nm UV lamp, and microfiltration capsule as standard. There is also the option to upgrade to an additional 185 nm UV lamp and ultrafiltration module, if required.
The Ultra is fitted with an intuitive full-colour touchscreen controller. The system can provide full details of both the inlet and outlet water, including temperature and conductivity. The advanced controller provides full information for ultimate reporting and accountability. This makes it ideal for sensitive work where technical parameters of both the feed and outlet water need to be reported accurately. Units are also fitted with alarms, which sound when modules need replacing.
Since it requires feed water of at least Type III, the Ultra series is ideal for use in laboratories with a pre-existing water purification system. Alternatively, use it in conjunction with a pre-treatment system (such as the Hydrolab Technical).
What’s in the box?
When your Hydrolab Ultra water purification unit is delivered, you will receive:
- Ultra water system with LCD display and integrated booster pump
- 2 L integrated storage tank
- TOC ionex resin cartridge
- 0.22μm microfiltration capsule
- 254nm UV lamp
- (Optional) 185nm/254nm UV lamp
- (Optional) Ultrafiltration capsule
- 2m tubing
- Connectors for water supply, drainage & tank
- Power lead with standard 230 V plug
- User manual
Features of the Hydrolab Ultra Series
- Purifies water to Type I using with the option to include a UV 185 nm UV lamp and ultrafiltration
- Double demineralisation using a mixed ion resin to produce water with conductivity < 0.06 μS/cm
- 254 nm UV lamp, with the option to add an additional 185 nm UV lamp
- Optional ultrafiltration module
- Purified water fits the ISO 3696: 1999, the ASTM, and the CLSI standards for the first purity class
- Obtained water is microbiologically and physiochemically compliant with the FP standard for the purified production water
- Obtained water may be used for: instrumental analyses: AAS, ICP/MS, IC, HPLC, GC; bacteria cultures; biochemical analyses
- Full colour touchscreen provides data on the temperature and conductivity of both inlet and outlet water. Also displays current date /time, system status, tank fill level, water dosing, and service schedule
- Audio and visual alarms for replacement of modules and lamps
- Includes 10 L water storage tank, supply and outlet connectors. Works on standard tap pressure, so can be installed by the user, without the requirement for specialist plumbing
- 12 months manufacturer warranty
Options
- Ultra: Unit includes an ion exchange TOC module, photooxidation module (254 nm), microfiltration capsule
- Ultra UV: As Ultra, plus 185/254 UV module
- Ultra UF: As Ultra UV, plus ultrafiltration module
